BENELLI TNT 1130 AND TRE-K BIKE WORKSHOP SERVICE REPAIR, OWNER'S MANUAL

BENELLI TNT 1130 AND TRE-K BIKE WORKSHOP SERVICE REPAIR, OWNER'S MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 1,475
FILE SIZE: 289MB

MODEL COVERED:

BENELLI TNT 1130

BENELLI TNT 1130 TRE-K


ENGINE COVERED:

1130 cc 3-CYLINDER IN-LINE, 4-STROKE, BORE X STROKE: 88 X62 mm, LIQUID-COOLED


CONTENTS:

GENERAL INFORMATION

SPECIFICATION

CHECK & ADJUSTMENT

COWLING SYSTEM

ENGINE REMOVAL

DISASSEMBLY & ASSEMBLY

CAMSHAFT/CYLINDERHEAD

VALVES & VALVE SPRING

CYLINDER & PISTON

GENERATOR SYSTEM

DISTRIBUTION SENSOR

CLUTCH SYSTEM

GEAR & MOUNTING GEAR

OIL SUMP & PUMP

CASING SYSTEM

COOLING SYSTEM

RADIATOR/THERMOSTAT

OIL DISTRIBUTOR

WATER PUMP

FRONT WHEEL/BRAKE DISC

REAR WHEEL-BRAKE-CROWN

FRONT & REAR BRAKES

FORK & HANDLEBAR

STEERING HEAD

REAR DAMPER & FORK

SUPPORT FRAME

TRANSMISSION CHAIN

ENGINE MANAGEMENT

SYSTEM DEVICES

ELECTRICAL PLANT

CONNECTORS/FUSES

BATTERY/RELAYS

STERTER/ALTERNATOR

SPEED/OIL PRESSURE SENSOR

SOLENOID SYSTEM

CHARGING SYSTEM

LIGHTING SYSTEM

DIAGNOSTIC PROCEDURE

FRAME & BODY

RESETTING THROTTLE

SELF-DIAGNOSIS

EXTRAS INCLUDED:

PARTS CATALOG MANUAL

OWNER'S MANUAL
