BOBCAT S330 SKID STEER LOADER SERVICE REPAIR, WIRING, OPERATOR'S MANUAL

BOBCAT S330 SKID STEER LOADER SERVICE REPAIR, WIRING, OPERATOR'S MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 3,476
FILE SIZE: 142MB

MODEL COVERED:

BOBCAT S330 SKID STEER LOADER

S/N A5HA11001 & ABOVE

S/N AAKM11001 & ABOVE

S/N A02011001 - A02059999

S/N A02111001 - A02159999

S/N A02060001 & ABOVE

S/N A02160001 & ABOVE

EQUIPPED WITH BOBCAT INTERLOCK CONTROL SYSTEM (BICS)

ENGINE:

KUBOTA / V3800DI-T-E3CB TIER III - DIESEL / LIQUID - 4 CYLINDERS

KUBOTA V3800-DI-T TURBO-CHARGED - DIESEL / LIQUID - 4 CYLINDERS

PART NO: 6987040, 6904887, 6986681

JULY, 2014

MARCH, 2009


CONTENTS:

MAINTENANCE SAFETY

FOREWARD

SAFETY & MAINTENANCE

HYDRAULIC SYSTEM

HYDROSTATIC SYSTEM

DRIVE SYSTEM

MAIN FRAME

ELECTRICAL SYSTEM & ANALYSIS

ENGINE SERVICE

HEATING, VENTILATION, AIR CONDITIONING (HVAC)

SPECIFICATIONS

ALPHABETICAL INDEX

SERVICE MANUAL REVISION

OPERATOR’S MANUAL:

S330:

S/N A02011001 - A02059999

S/N A02111001 - A02159999

PART NO:

6904789 - OCTOBER, 2007 (APRIL, 2008)

S330:

S/N A5HA11001 & ABOVE

S/N AAKM11001 & ABOVE

PART NO:

6986973 - APRIL, 2010 (REVISED - NOVEMBER, 2010)

S330:

S/N A02060001 & ABOVE

S/N A02160001 & ABOVE

PART NO:

6986995 - MARCH, 2008 (REVISED - APRIL, 2008)

EXTRAS INCLUDED:

ELECTRIC HYDRAULIC SCHEMATICS
