CASE 327B 330B ARTICULATED DUMP TRUCK FACTORY WORKSHOP SERVICE REPAIR MANUAL

CASE 327B 330B ARTICULATED DUMP TRUCK FACTORY WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 2,490
FILE SIZE: 222MB

MODEL COVERED:

CASE 327B 330B ARTICULATED DUMP TRUCK

PRINT NO: 87573455A

MARCH, 2007

PRINT NO. 84187913

FIRST EDITION

SEPTEMBER, 2009

FROM SERIAL NO. ZCNAD30TP8P457003


CONTENTS:

SECTION 1-CONDITIONS OF USE AND SAFETY INSTRUCTIONS

SECTION 2-TECHNICAL DATA

SECTION 3-FAULT CODES

SECTION 4-ENGINE

SECTION 5-AUTOMATIC TRANSMISSION

SECTION 6.1-FRONT AXLE

SECTION 6.2-INTERMEDIATE AXLE

SECTION 6.3-REAR AXLE

SECTION 7-DRIVELINE

SECTION 8-SUSPENSIONS

SECTION 9-WHEELS AND TIRES

SECTION 10-HYDRAULIC SYSTEM

SECTION 10.1-STEERING AND DUMPING SYSTEM

SECTION 10.2-EMERGENGY STEERING SYSTEM

SECTION 10.3-BRAKING SYSTEM

SECTION 11-ELECTRICAL SYSTEM

SECTION 12-PNEUMATIC SYSTEM

SECTION 13-GREASE SYSTEM

SECTION 14-AIR CONDITIONING SYSTEM

SECTION 15-CAB

SECTION 16-CHASSIS
