CASE CX180C LC TIER 3 CRAWLER EXCAVATOR WORKSHOP SERVICE REPAIR, WIRING MANUAL

CASE CX180C LC TIER 3 CRAWLER EXCAVATOR WORKSHOP SERVICE REPAIR, WIRING MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 9,526
FILE SIZE: 585MB

MODEL COVERED:

CASE CX180C

CX180C CRAWLER EXCAVTOR - LC - BRAZIL MARKET - TIER3

CX180C CRAWLER EXCAVATOR LC VERSION (TIER 3)

ISSUED:

PART NUMBER 48024894

MAY 2017

PART NUMBER 48037141

JULY 2016

PART NUMBER 48139070

APRIL 2017


CONTENTS:

INTRODUCTION

ENGINE

HYDRAULIC SYSTEMS

TRACKS AND TRACK SUSPENSION

CAB CLIMATE CONTROL

ELECTRICAL SYSTEMS

PLATFORM, CAB, BODYWORK, AND DECALS

SPECIAL TOOL INDEX

HYDRAULIC SCHEMATIC

ELECTRICAL SCHEMATIC

ELECTRICAL SCHEMATIC (GPS)-EXCAVATOR-48063139EN

ELECTRICAL SCHEMATIC-CX180C EXCAVATOR 48139072EN

HYDRAULIC SCHEMATIC-CX180C EXCAVATOR-48139071EN
