CASE IH FARMLIFT 633 636 737 742 935 STAGE IV TELESCOPIC HANDLER WORKSHOP SERVICE MANUAL

CASE IH FARMLIFT 633 636 737 742 935 STAGE IV TELESCOPIC HANDLER WORKSHOP SERVICE MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 3,191
FILE SIZE: 110MB

MODEL COVERED:

CASE IH FARMLIFT 633 636 737 742 935 STAGE IV

FARMLIFT 633 STAGE IV 6 M (19.7 FT), 99 KW (133 HP) [FNHZP633NJKE00001- ]

FARMLIFT 636 STAGE IV 6 M (19.7 FT), 107 KW (145 HP) [FNHZK634NJKE00001- ]

FARMLIFT 737 STAGE IV 7 M (22.9 FT), 99 KW (133 HP) [FNHZP737NJKE00001- ]

FARMLIFT 742 STAGE IV 7 M (22.9 FT), 107 KW (145 HP) [FNHZK742NJKE00001- ]

FARMLIFT 935 STAGE IV 9 M (29.5 FT), 99 KW (133 HP) [FNHZP935NJKE00001- ]

ENGINE:

F4HFE4149*B001

F4HFE413Z*B002

ISSUED:

PART NUMBER 51546954

OCTOBER, 2018


CONTENTS:

INTRODUCTION

ENGINE

TRANSMISSION

FOUR-WHEEL DRIVE (4WD) SYSTEM

FRONT AXLE SYSTEM

REAR AXLE SYSTEM

BRAKES AND CONTROLS

HYDRAULIC SYSTEMS

STEERING

CAB CLIMATE CONTROL

ELECTRICAL SYSTEMS

TELESCOPIC SINGLE ARM

PLATFORM, CAB, BODYWORK, AND DECALS

SPECIAL TOOL INDEX
