Product description

CASE IH INTERNATIONAL 2090 2290 TRACTOR FACTORY WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 1,755
FILE SIZE: 795MB


MODEL COVERED:

CASE IH 2090 & 2290 TRACTOR

PART NUMBER: 8-20000

MAY, 1985


CONTENTS:

GENERAL

General Specifications - 2090 Tractors

General Specifications - 2290 Tractors

Lubrication - 2090 Tractors

Lubrication - 2290 Tractors

Engine Specifications 504BDT Engine

Engine Specifications 504BD Engine

Fuel System Specifications

Steering Specifications

Power Train Specifications

Brake System Specifications

Hydraulic System Specifications

ENGINES

Trouble Shooting - Engine

Engine Tune-Up

Tractor Split (Between Engine and Torque Tube)

Cylinder Head, Valve Train and Camshaft

Cylinder Block, Sleeves, Pistons and Rods

Crankshaft, Main Bearing, Flywheel and Oil Seals

Lubrication System - Oil Pump, Oil Pan and Heat Exchanger

Cooling System

Turbocharger - T04B

Turbocharger Failure Analysis

Air Induction System - 2290 Tractors

Air Cleaner System - 2090 Tractors

Reconditioning Engine Cylinder Block

FUEL SYSTEM

Fuel System and Filters

Robert Bosch Fuel Injection Pumps

American Bosch Fuel Injectors

ELECTRICAL

Electrical System Troubleshooting

Tractor Electrical Wiring Diagram (Prior to P.l.N. 8841101)

Tractor Electrical Wiring Diagram {P.l.N. 8841101 and After)

Cab Electrical Wiring Diagram (Prior to Cab SN12008153)

Cab Electrical Wiring Diagram (Cab SN12008153 and After)

Starting Motors - Delco-Remy

Starting Motors - Nippondenso

Battery Servicing and Testing

Delco-Remy Alternator System

Neutral Start Switch Adjustment and Correct Starting

Procedure Using Booster Batteries

STEERING

Testing Tractor Steering System

Steering Column, Pump and Valve

Steering Cylinder

Front Steering Axle and lines

POWER TRAIN

Trouble Shooting - RPS-34 Power Shift Transmission and PTO

Testing RPS-34 Power Shift Transmission and PTO

Hydraulic Pump Drive

Hydraulic PTO - 540 and 1000 RPM

Hydraulic PTO - 1000 RPM

Rear Axles and Planetaries

Differential and Differential Lock

Mechanical Shift Tractors

Tractor Split (Between Torque Tube and Transmission)

Master Hydraulic Clutch

Hi-Lo and Reverse Range

Master Clutch Valve and Linkage

Four Speed Transmission

Power Shift Tractors

Torque Limiter Clutch

RPS-34 Power Shift

RPS-34 Control Valve and Linkage

Four Speed Transmission

BRAKES

Power Assist Unit and Pedals

Park Lock System

Brake Cylinders

HYDRAULIC

Trouble Shooting - Hitch System

Testing Tractor Hydraulic System

Hydraulic Oil Filters

Hydraulic Charging Pump

Hydraulic Pump

Remote Hydraulic Valves

Flow Divider and PTO Control Valve

Hitch System

Break-Away Couplings and Portable Cylinders

ACCESSORIES

Trouble Shooting - Air Conditioning System

Gauging and Testing Air Conditioning System

Compressor Isolation, Removal, Installation and Evacuation

Discharging, Evacuation and Charging the Air Conditioning System

Servicing Air Conditioner Components

Servicing the Cab Blower

Operators Seat Adjustments

Removal of Tilting Hood, Grill and Side Panels

Removal of Sliding Hood, Grille and Side Panels

HOW IT WORKS

Tractor Hydraulics System Oil Flows

Case CON TROL Hydraulics
