CASE MODEL 530CK 530 CONSTRUCTION KING BACKHOE LOADER WORKSHOP SERVICE MANUAL

CASE MODEL 530CK 530 CONSTRUCTION KING BACKHOE LOADER WORKSHOP SERVICE MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 783
FILE SIZE: 126MB

MODEL COVERED:

CASE MODEL 530CK 530 CONSTRUCTION KING BACKHOE LOADER

ALL MODELS/ENGINES/TRIM/TRANSMISSIONS TYPES ARE COVERED


CONTENTS:

SECTION IX - MODEL 530 CONSTRUCTION KING LOADER AND BACKHOE

SECTION C - SPECIFICATIONS FOR 188 DYNACLONIC DIESEL AND 148 POWER- TORQ GASOLEN ENGINES

SECTION C - SPEICICATIONS FOR 188 DYNACLONIC DIESEL AND 159 POWER - TORG GASOLINE ENGINES

SECTION F - ELECTRICAL SYSTEM

SECTION 2013- CYLINDER HEAD AND VALVES 148, 159, 188 AND 201 SPARK IGNITION ENGINES

SECTION 2014 CYCLINDER HEAD AND VALVES 188 DIESEL ENGINES

SECITON 2023 ENGINE BLOCK ASSEMBLIES 201G, 188G, 159G, 148G SPARK IGNITION ENGINES

SECTION 2024 ENGINE BLOCK ASSEMBLY 188D DIESEL ENGINE

SECTION I - SERVICING THE CAV FUEL INJECTORS

SECTION I SUPPL - ADJUSTING THE THROTTLE LINKAGE ON THE 430-530 SERIES TRACTORS

SECTION 3022 - ROOSA MASTER 188 SERIES DIESEL ENGINES

SECTION 3033 - 267 SEREIS CARBURETOR

SECTION 4019 BREAK AWAY COUPLING AND PORTABLE HYDRAULIC CYCLINDERS

SECTION D - SERVICING REMORT HYDRAULIC VALVES

SECTION O SERVICING TH HYDROSTATIC STEERING, POWER PUMP, CONTROL VALVE, MAQNUAL PUMP, CYCLINDERS

SECTION R - SERVICING DRAFT-O MATIC HYDRAULIC SYSTEM, VALVE, ROCKSHAFT ASSEMBLY

SECTION 3S - SERVICING CONSTANT RUNNING POWER TAKE - OFF

SECTION 65 - FOUR SPEED TRANSMISSION AND FINAL DRIVE

SECTION XIV - 32S SIDE SHIFT BACKHOE

SECTION 66 - MECHANICAL SHUTTLE

SECTION 67 - DUAL RANGE ASSEMBLY

SECTION 68 - 11 INCH TRACTION CLUTCH

SECTION 74 - DIFFERNTAIL BRAKS, DIFFERENTIAL LOCK AND PARKING BRAKE

SECTION XIV MODEL 32S SIDE SHIFT BACKHOE

SECTION X SERVICING CASE-O-MATIC, 11-INCH TOGQUE CONVERTER, CONTROL VALVE, PRESSURE REQULATOR AND OIL PUMPL

SECTION 92 - SPLITING THE 480-580 B TRACTORS
