CATERPILLAR CAT 6D16 AND 6M60-TL DIESEL ENGINE SERVICE REPAIR MANUAL

CATERPILLAR CAT 6D16 AND 6M60-TL DIESEL ENGINE SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 635
FILE SIZE: 23.4MB

ENGINE COVERED:

6D16 Diesel Engine

DP80 T32B-00011-up

DP90 T32B-50001-up

DP100 3DP-00001-up

DP115 4DP-00001-up

DP135 5DP-00001-up

DP150 6DP-00011-up

PART NO: 99709-68130

6M60-TL Diesel Engine

P17500-P36000

DP80N-DP160N

PART NO: 99709-61100


CONTENTS:

GENERAL

ENGINE

LUBRICATION

FUEL AND ENGINE CONTROL

ELECTRONICALLY CONTROLLED FUEL SYSTEM

COOLING

INTAKE AND EXHAUST

EMISSION CONTROL

ELECTRICAL

SPECIAL EQUIPMENT

The Caterpillar (CAT) 6D16 is a 7.5-liter, 6-cylinder, 4-cycle water-cooled diesel engine, frequently used in Caterpillar lift trucks (DP80–DP150) and Mitsubishi Fuso vehicles. It is a direct-injection engine known for its reliability and durability in heavy-duty applications.

The Caterpillar (CAT) 6M60-TL is a 7.5-liter, 6-cylinder, inline, water-cooled diesel engine, commonly used in heavy-duty Caterpillar forklifts (e.g., DP80N, P22000, FD100N). The 6M60-TL is generally produced by Mitsubishi Fuso and branded for CAT, featuring a 4-cycle, direct-injection design with turbocharging and intercooling (after-cooled) to maximize efficiency.
