CESAB R216 ELECTRIC REACH TRUCK SERVICE REPAIR, PARTS, OPERATOR'S MANUAL

CESAB R216 ELECTRIC REACH TRUCK SERVICE REPAIR, PARTS, OPERATOR'S MANUAL
LANGUAGE: ENGLISH, MULTI-LANGUAGE
FORMAT: PDF
PAGES: 3,184
FILE SIZE: 141MB

MODEL COVERED:

CESAB R216 ELECTRIC REACH TRUCK

T-CODE: MODEL: SERIAL NUMBER:

483 R212 6111575-

484 R212 6111575-

657 R214 6111575-

658 R214 6111575-

793 R216 6111575-

794 R216 6111575-

SERIAL NUMBER:

6111575 - UP

PART NO:7519087-040

ISSUED:

OCTOBER, 2016


CONTENTS:

2- General introduction

3- General safety rules

4- installation

5- Technical data 1

6- Technical data 2

7- Introduction, maintenance

8- Preventive maintenance

9- Oil and grease specifications

10- tools

11- Operator protection – 0840

12- Electric pump motor – 1710

13- Electric steering motor – 1730

14- Electric drive motor – 1760.1

15- Electric drive motor – 1760.2

16- Drive unit/gear – 2550.1

17- Drive unit/gear – 2550.2

18- Service brake system – 3100.1

19- Service brake system – 3100.2

20- Drive wheel – 3530

21- Fork/support arm wheel – 3550

22- Mechanical steering system – 4100

23- Steering angle sensor – 4350

24- Electrical system – 5000.1

25- electrical system – 5000

26- battery – 5110

27- Transistor panel – 5460

28- Power electronic panel – 5660

29- Logic card 5710

30- hydraulics – 6000

31- Hydraulic pump – 6140

32- Hydraulic couplings – 6230

33- Mast-mounted hose reel – 6370

34- Hydraulic cylinder – 6600

35- Main lift cylinder – 6610

36- Free lift cylinder – 6620

37- Reach cylinder – 6650

38- Tilt cylinder – 6660.1

39- Tilt cylinder – 6660.2

40- Main mast/mast – 7100.1

41- Main mast/mast – 7100.2

42- Main lift chain system – 7120

43- Lifting devices – 7400

44- Battery charger – 8340

45- extra lighting– 9360

46.1 general

47- Positioning/TV equipment – 9390

48- Truck log system, code lock – 9420.1

49- Extra equipment – 9500

50- Disposal instructions

EXTRAS INCLUDED:

OPERATOR'S MANUAL

PARTS MANUAL
