CLARK C15 C20 C25 C30 C35 GEN 2 FORKLIFT TRUCK WORKSHOP SERVICE REPAIR, PARTS MANUAL

CLARK C15 C20 C25 C30 C35 GEN 2 FORKLIFT TRUCK WORKSHOP SERVICE REPAIR, PARTS MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 4,978
FILE SIZE: 258MB

MODEL COVERED:

CLARK C15C, C18C, C20sC, C20C, C25C, C30C, C32C  CUSHION TIRE TYPE GAS & LPG FORKLIFT TRUCK

CLARK C15, C18, C20s, C20, C25, C30, C35  PNEUMATIC TIRE TYPE GAS & LPG FORKLIFT TRUCK

CLARK C15, C18, C20s, C20, C25, C30, C35  DIESEL FORKLIFT TRUCK


ENGINE COVERED:

2.0L 4-CYLINDER INLINE, 4-STROKE, WATER-COOLED, OHC, MITSUBISHI 4G63 PETROL/LPG ENGINE

2.4L 4-CYLINDER INLINE, 4-STROKE, WATER-COOLED, OHC, MITSUBISHI 4G64 PETROL/LPG ENGINE

3.1L 4-CYLINDER INLINE, 4-STROKE, WATER-COOLED, YANMAR 4TNV94L DIESEL ENGINE

2.2L 4-CYLINDER INLINE, 4-STROKE, WATER-COOLED, YANMAR 4TNV88 DIESEL ENGINE

CONTENTS:

GENERAL INFORMATION

GENERAL PRECAUTIONS

SPECIFICATIONS

PERIODIC MAINTENANCE

SPECIAL TOOLS

TIGHTENING TORQUE

LUBRICATION CHART

ENGINE REMOVAL

ENGINE INSTALLATION

ENGINE TUNE-UP SYSTEM

ENGINE OIL AND FILTER

ENGINE COOLING SYSTEM

RADIATOR REMOVAL & REPLACEMENT

LPG FUEL SYSTEM (CARBURETED)

LPG CARBURETOR & THROTTLE BODY

CARBURATOR SYSTEM

INTAKE MANIFOLD SYSTEM

EXHAUST MANIFOLD SYSTEM

VAPORIZER-REGULATOR

FUEL LOCK-OFF & FILTER

AIR GOVERNOR SYSTEM

MI-4 LPG SYSTEM

N2001 PRESSURE REGULATOR/CONVERTER

N-CA55-500TR AIR/FUEL MIXER

AIR INDUCTION SYSTEM

EXHAUST SYSTEMS

IGNITION SYSTEM

DISTRIBUTOR OVERHAUL

TRANSAXLE CONTROL VALVE

TRANSAXLE-DRIVE AXLE

ELECTRICAL SYSTEM

INSTRUMENT POD SYSTEM

CUSHION WHEELS AND TIRES

PNEUMATIC WHEELS AND TIRES

BRAKING/INCHING SYSTEM

PARKING BRAKE SERVICE

STEERING SYSTEM

STEERING COLUMN AND GEAR

STEER AXLE-STEER CYLINDER

HYDRAULIC SYSTEM

HYDRAULIC PUMP OVERHAUL

AUXILIARY PUMP OVERHAUL

HYDRAULIC VALVE OVERHAUL

UPRIGHT-MAST-CARRIAGE

CHAINS AND FORKS SYSTEM

LIFT AND TILT CYLINDERS

LIFT CHAIN SERVICE

COUNTERWEIGHT SYSTEM

OVERHEAD GUARD/OPERATOR’S CELL

FLOORBOARD, COWLS, RADIATOR COVER

OPERATOR’S SEAT & SEAT DECK

TROUBLESHOOTING

HYDRAULIC SYSTEM SCHEMATIC

ELECTRICAL WIRING DIAGRAMS
