CLARK SF CMP 35 40 45 50 D L SD SL SERIES FORKLIFT WORKSHOP SERVICE REPAIR MANUAL
⚫ Instant Download
⚫ No Physical Shipping
Guarantee safe & secure checkout
CLARK SF CMP 35 40 45 50 D L SD SL SERIES FORKLIFT WORKSHOP SERVICE REPAIR MANUAL
CLARK SF CMP 35 40 45 50 D L SD SL SERIES FORKLIFT WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 1,668
FILE SIZE: 174MB
MODEL COVERED:
CLARK SF35D, SF40D, SF45D FORKLIFT TRUCK
CLARK SF35L, SF40L, SF45L FORKLIFT TRUCK
CLARK CMP40D, CMP45D, CMP50SD FORKLIFT TRUCK
CLARK CMP40L, CMP45L, CMP50SL FORKLIFT TRUCK
ISSUED:
SM-690 (JUNE, 2004)
SM-713 (MARCH, 2004)
ENGINE COVERED:
4.00L 4-CYLINDER, NATURALLY ASPIRATED/TURBOCHARGED, PERKINS 1004-4 DIESEL ENGINE
4.23L 4-CYLINDER INLINE, NATURALLY ASPIRATED, PERKINS 1004-42 DIESEL ENGINE
4.41L 4-CYLINDER INLINE, NATURALLY ASPIRATED/TURBOCHARGED PERKINS 1104C-44 DIESEL ENGINE
4.30L 6-CYLINDER V-TYPE V6, GM LPG ENGINE
CONTENTS:
GENERAL INFORMATION
GENERAL PRECAUTIONS
SPECIFICATIONS
PERIODIC MAINTENANCE
SPECIAL TOOLS
TIGHTENING TORQUE
LUBRICATION CHART
ENGINE SYSTEM
ELECTRIC COMPONENT
DISTRIBUTOR SYSTEM
ALTERNATOR SYSTEM
STARTER SYSTEM
FUEL PUMP SYSTEM
FUEL SYSTEM
ASPIRATION SYSTEM
LPG AND LPG FUEL TANKS
N-CA100TR AIR/FUEL MIXER
INTAKE SYSTEM
AIR GOVERNOR SYSTEM
COOLING WATER SYSTEM
LUBRICATING OIL & FUEL OIL
FUEL INJECTION PUMP
DIRECT INJECTION SYSTEM
EMISSION CONTROL SYSTEM
LUBRICATION SYSTEM
ENGINE TUNING SYSTEM
TRANSAXLE-TRANSMISSION
SERVICE BRAKE SYSTEM
PARKING BRAKE SYSTEM
BRAKE VALVE SYSTEM
DIFFERENTIAL SYSTEM
STEERING SYSTEM
POWERSHIFT TRANSMISSION
PRIORITY VALVE-STEERING UNIT
BRAKE / INCHING BLEEDING
HYDRAULIC SYSTEM
AUXILIARY PUMP
START-UP SYSTEM
HYDRAULIC MAIN PUMP
MAIN HYDRAULIC VALVE
HYDRAULIC CYLINDERS
LIFT CYLINDER SYSTEM
TILT CYLINDER SYSTEM
STEERING CYLINDER SYSTEM
W SERIES GEAR PUMP
DOUBLE PUMP SYSTEM
REVERSE SHAFT ROTATION
HYDRAULIC MAST MAINTENANCE
STANDARD/FULL FREE LIFT/TRIPLE MAST
CARRIAGE-CYLINDER RACKING
LIFT CHAINS-FORKS SYSTEM
HYDRAULIC SYSTEM PRESSURE SETTING
CARRIAGE AND UPRIGHT ROLLER
COUNTERWEIGHT SYSTEM
LIFTING, JACKING AND BLOCKING
TROUBLESHOOTING ANALYSIS
HYDRAULIC CIRCUIT DIAGRAM
ELECTRICAL WIRING DIAGRAMS
