CUMMINS M11 SERIES DIESEL ENGINE WORKSHOP SERVICE REPAIR MANUAL
⚫ Instant Download
⚫ No Physical Shipping
Guarantee safe & secure checkout
CUMMINS M11 SERIES DIESEL ENGINE WORKSHOP SERVICE REPAIR MANUAL
CUMMINS M11 SERIES DIESEL ENGINE WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 1,511
FILE SIZE: 34.7MB
|
GENERAL ENGINE DATA:: |
|
Horsepower (Refer to the engine dataplate) Engine speed @ Maximum Output: • Governed Speed (RPM) - Automotive ..........1800 • Governed Speed (RPM) - Vocational ..........2000 • Advertised HP (RPM) ........................1600 Bore and Stroke ..............................125 mm [4.921 in] X 147 mm [5.787 in] Displacement .................................10.8 liters [661 C.I.D.] Firing Order .................................1-5-3-6-2-4 Engine Weight (with Standard Accessories): • Dry Weight .................................940 Kg [2070 lb] • Wet Weight .................................996 Kg [2193 lb] Crankshaft Rotation - (viewed from the front of the engine) .....Clockwise |
CONTENTS:
INTRODUCTION
ENGINE DIS-ASSEMBLY
ENGINE ASSEMBLY
CYLINDER BLOCK
CYLINDER HEAD
ROCKER LEVERS
CAM FOLLOWERS
FUEL SYSTEM
INJECTORS AND FUEL LINES
LUBRICATING OIL SYSTEM
COOLING SYSTEM
DRIVE UNITS
AIR INTAKE SYSTEM
EXHAUST SYSTEM
AIR EQUIPMENT
ELECTRICAL EQUIPMENT
ENGINE TESTING
INSTRUMENTS AND CONTROLS
MOUNTING ADAPTIONS
SPECIFICATIONS
VEHICLE BRAKING
SERVICE LITERATURE
COMPONENT MANUFACTURERS
