CUMMINS QSK19 QSK 19 SERIES DIESEL ENGINE WORKSHOP SERVICE REPAIR MANUAL
⚫ Instant Download
⚫ No Physical Shipping
Guarantee safe & secure checkout
CUMMINS QSK19 QSK 19 SERIES DIESEL ENGINE WORKSHOP SERVICE REPAIR MANUAL
CUMMINS QSK19 QSK 19 SERIES DIESEL ENGINE WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 634
FILE SIZE: 11.2MB
|
GENERAL ENGINE SPECIFICATIONS: |
|
Engine Speed ..........Refer to the fuel pump calibration data for optional speed rating. Displacement ..........19 liters [1150 C.I.D.] Bore and Stroke .......158.75 mm x 158.75 mm [6.25 in x 6.25 in] Engine Weight: Dry ...................1720 kg [3800 lb] Wet ...................2045 kg [4504 lb] Firing Order ..........1-5-3-6-2-4 Valve and injector settings: Intake valve adjustment ........0.36 mm [0.014 in] Intake valve limits ............0.28 to 0.43 mm [0.011 to 0.017 in] Exhaust valve adjustment .......0.81 mm [0.032 in] Exhaust valve limits ...........0.74 to 0.89 mm [0.029 to 0.035 in] Injector OBC Method adjustment (in engine) .........19 N•m [165 in-lb] Compression Ratio: 525 HP to 600 HP-Jacket Water Aftercooled (JWAC) .........17.0:1 600 HP to 750 HP-Low Temperature Aftercooled (LTA) .......15.0:1 Crankshaft Rotation (Viewed from the front of the engine) ...Clockwise |
CONTENTS:
INTRODUCTION
ENGINE IDENTIFICATION
COMPLEATE ENGINE
CYLINDER BLOCK
CYLINDER HEAD
ROCKER LEVERS
CAM FOLLOWERS/TAPPETS
FUEL SYSTEM
INJECTORS AND FUEL LINES
LUBRICATING OIL SYSTEM
COOLING SYSTEM
AIR INTAKE SYSTEM
EXHAUST SYSTEM
DRIVE UNITS
ELECTRICAL EQUIPEMENT
ENGINE TESTING
COMPRESSED AIR SYSTEM
MOUNTING ADAPTIONS
ELECTRONIC ENGINE CONTROLS
SERVICE LITERATURE
COMPONENT MANUFACTURERS
SPECIFICATIONS
