DODGE MAGNUM SRT-8 42RLE W5A580 NAG1 2004-2008 WORKSHOP SERVICE MANUAL

DODGE MAGNUM SRT-8 42RLE W5A580 NAG1 2004-2008 WORKSHOP SERVICE MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 9528
FILE SIZE: 211MB

ENGINE COVERED:

3.0L TD Common Rail Diesel Engine

2.7L EER V-6 Cylinder, 24 Valve, DOHC, Gasoline, Aluminum Block (MPI)

3.5L EGG V-6 Cylinder, 24 Valve, High Output, Gasoline, Aluminum Block (MPI)

6.1L ESF V-8 Cylinder, HEMI, Gasoline (SMPI)

5.7L EZB V-8 Cylinder, HEMI, Multi-Displacement, Gasoline


TRANSMISSION COVERED:

4 Speed 42RLE Automatic

5 Speed W5A580/NAG1 Automatic


CONTENTS:

INTRODUCTION

LUBRICATION & MAINTENANCE

SUSPENSION

DIFFERENTIAL & DRIVELINE

VEHICLE QUICK REFERENCE

BRAKES

COOLING

AUDIO/VIDEO

CHIME/BUZZER

CLOCK

ELECTRONIC CONTROL MODULES

ENGINE SYSTEMS

HEATED SYSTEMS

HORN

IGNITION CONTROL

INSTRUMENT CLUSTER

LAMPS

MESSAGE SYSTEMS

POWER SYSTEMS

RESTRAINTS

SPEED CONTROL

VEHICLE THEFT SECURITY

WIPERS/WASHERS

NAVIGATION/TELECOMMUNICATION

WIRING

ENGINE

EXHAUST SYSTEM

FRAME & BUMPERS

FUEL SYSTEM

STEERING

AUTOMATIC TRANSMISSION

TIRES/WHEELS

BODY

HEATING & AIR CONDITIONING

EMISSIONS CONTROL

NB: This manual is for the Dodge Charger LX Magnum, but it is quite similar to the Dodge Magnum SRT-8 and Chrysler 300 SRT-8 models.
