DUCATI 1098 1098S 2007-2008 BIKE SERVICE REPAIR MANUAL

DUCATI 1098 1098S 2007-2008 BIKE SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 714MB
FILE SIZE: 32.3MB

ENGINE SPECIFICATION:

Type.................Longitudinal 90º “L” twin cylinder, four-stroke

Bore.................104 mm

Stroke...............64.7 mm

Displacement.........1099 cm³

Compression ratio....12.5 ± 0.5:1

Max power at crankshaft (95/1/EC)...113 kW (156 CV) @ 9750 rpm

Max power at crankshaft on acceleration bench...117 kW (160 CV) @ 9750 rpm

Max torque at crankshaft (95/1/EC)...116 Nm (10.81 Kgm) at 8000 rpm

Maximum crankshaft torque measured on

acceleration bench......122 Nm (11.1 Kgm) at 8000 rpm

Idling speed........1300±50 rpm

Max. engine speed....10700 rpm

Timing system.....With toothed belt, double overhead camshaft, 4 valves per cylinder and 8 rocker arms

Lubrication system....Forced lubrication by pump, with oil cooler

Oil pump type......Gear pump

Cooling system.....Liquid cooling

Air filter.....Two filter units

Crankshaft type… One-piece

CONTENTS:

GENERAL INFORMATION

INFORMATION ABOUT THE MODEL

TECHNICAL DATA

USE AND MAINTENANCE

FAIRINGS

CONTROLS-DEVICES

WHEEL

SUSPENSION

BRAKES

FRAME

FUEL SYSTEM

EXHAUST SYSTEM

INJECTION SYSTEM

IGNITION SYSTEM

ENGINE

ELECTRIC SYSTEM
