DUCATI MONSTER 696 2008-2010 BIKE WORKSHOP SERVICE REPAIR MANUAL

DUCATI MONSTER 696 2008-2010 BIKE WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: HTML (WINDOWS COMPUTER ONLY)
COMPATIBILITY: WINDOWS 7, 8
PAGES: UNKNOWN
FILE SIZE: 180MB

ENGINE SPECIFICATION:

Type.................Longitudinal 90º “L” twin cylinder, four-stroke

Bore.................88 mm

Stroke...............57.2 mm

Displacement.........696 cm³

Compression ratio....10.7 ± 0.5:1

Timing system.....With toothed belt,Single overhead camshaft,2 valves per cylinder and 4 rocker arms

Lubrication system....Forced lubrication by pump, with oil cooler

Oil pump type......Gear pump with bypass valve

Cooling system.....Air Cooled

Air filter.....Filter element in the airbox

Crankshaft type... One-piece

CONTENTS:

GENERAL INFORMATION

INFORMATION ABOUT THE MODEL

TECHNICAL DATA

USE AND MAINTENANCE

FAIRINGS

CONTROLS-DEVICES

WHEEL

SUSPENSION

BRAKES

FRAME

FUEL SYSTEM

EXHAUST SYSTEM

INJECTION SYSTEM

IGNITION SYSTEM

ENGINE

ELECTRIC SYSTEM

SPARE PARTS CATALOG
