FORD 8630 8730 8830 ULTRA COMMAND POWERSHIFT TRANSMISSION SERVICE MANUAL

FORD 8630 8730 8830 ULTRA COMMAND POWERSHIFT TRANSMISSION SERVICE MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 406
FILE SIZE: 84.6MB

MODEL COVERED:

FORD 8630 8730 8830 ULTRA COMMAND POWERSHIFT TRANSMISSION

ISSUED:

PART NO:40863030

MARCH, 1990


CONTENTS:

TRANSMISSION SYSTEMS

CHAPTER 1

SEVEN AND EIGHT SPEED TRANSMISSIONS

A. TRANSMISSION - DESCRIPTION AND OPERATION

B. PARKING BRAKE ACTUATOR, ROD AND LINKAGE ADJUSTMENT

c. GEARSHIFT MECHANISM - OVERHAUL AND ADJUSTMENT

D. GEARSHIFT COVER AND INTERLOCK MECHANISM -OVERHAUL

E. TRANSMISSION REAR END - OVERHAUL

F. TRANSMISSION FRONT END - OVERHAUL

G. EIGHT-SPEED TRANSMISSION - COMPLETE OVERHAUL

H. SEVEN-SPEED TRANSMISSION - COMPLETE OVERHAUL

Chapter 2

DUAL POWER TRANSMISSION

A. DUAL POWER TRANSMISSION-DESCRIPTION AND OPERATION

B. PLANETARY GEARSET - OVERHAUL

c. PRESSURE TESTING

Chapter 3

LOW PRESSURE HYDRAULIC SYSTEM

Section

A. DESCRIPTION AND OPERATION

8. REGULATING VALVE

C. PRESSURE TESTING

Chapter 4

TROUBLE SHOOTING, SPECIFICATIONS AND

SPECIAL TOOLS

Section

A. TROUBLE SHOOTING

B. SPECIFICATIONS

C. SPECIAL TOOLS

Chapter 5

{Post March 1990)

ULTRA-COMMAND™ POWERSHIFT TRANSMISSION

FORD 8630, 8730 and 8830

Section Page

A. TRANSMISSION-DESCRIPTION AND OPERATION 1

B. OPERATING CONTROLS- DESCRIPTION AND OPERATION 16

C. HYDRAULIC CONTROL VALVE- DESCRIPTION

AND OPERATION 20

D. ELECTRONIC MANAGEMENT SYSTEM - DESCRIPTION

AND OPERATION 25

E. TRANSMISSION - OVERHAUL 31

F. OPERATING CONTROLS - OVERHAUL 54

G. HYDRAULIC CONTROL VALVE-OVERHAUL 62

H. ELECTRONIC MANAGEMENT SYSTEM -OVERHAUL 71

Chapter 6

{Post March 1990)

POWERSHIFT TRANSMISSION CALIBRATION,

INITIAL TESTS AND LIMP HOME, WIRING CIRCUITS,

TROUBLE SHOOTING, PRESSURE TESTING,

SPECIFICATIONS AND SPECIAL TOOLS

FORD 8630, 8730 and 8830

Section

A. CALIBRATION, INITIAL TESTS AND LIMP HOME

B. WIRING CIRCUITS

C. TROUBLE SHOOTING

D. PRESSURE AND FLOW TESTING

E. SPECIFICATIONS

F. SPECIAL TOOLS

EXTRAS INCLUDED:

FORD 8530, 8630, 8730 & 8830 OPERATOR'S MANUAL
