HINO 300 SERIES TRUCK BODY AND CHASIS SERVICE REPAIR MANUAL

HINO 300 SERIES TRUCK BODY AND CHASIS SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 169
FILE SIZE: 6.79MB


VEHICLE MODEL COVERED:

HINO 3414(MODEL): XZU307L-HKMLB3(PRODUCTION CODE)

HINO 3614(MODEL): XZU307L-HKMMB3 / XZU347L-HKMMB3(PRODUCTION CODE)

HINO 3616(MODEL): XZU407L-HKMMD3 / XZU407L-HKMQD3 / XZU417L-HKMMD3(PRODUCTION CODE)

HINO 3716(MODEL): XZU407L-HKFQD3 / XZU417L-HKFQD3 / XZU427L-HKFQD3(PRODUCTION CODE)

HINO 3816(MODEL): XZU407L-HKFRD3 / XZU417L-HKFRD3 / XZU427L-HKFRD3(PRODUCTION CODE)

HINO 3714(MODEL): XKU417L-HKFQB3(PRODUCTION CODE)


CONTENTS:

VEHICLE SUMMARY

GENERAL PRECAUTIONS

IDENTIFICATION NUMBER

CHASSIS SPECIFICATIONS

CHASSIS MASS & FRAME SECTION MODULUS

SPRING & REAR AXLE

SPRING CHARACTERISTICS

MAXIMUM VERTICAL DEFLECTION OF REAR WHEELS

TRAVEL RANGE OF REAR SPRING

PTO AND CONTROL

LAYOUT OF POWER LINE

TRANSMISSION SIDE POWER TAKE OFF (OPT)

ENGINE CONTROL FOR BODY OR EQUIPMENT

REAR BODY CONTROL LEVER (OPT)

ELECTRICAL SYSTEMS

FUSE BLOCK AND RELAY PANEL

ALTERNATOR OUTPUT CHARACTERISTIC

SPARE POWER TERMINALS

ADDITIONAL LAMPS

REAR COMBINATION LAMP

LICENSE PLATE BRACKET AND LICENSE PLATE LAMP

BACK-UP BUZZER

ELECTRICAL WIRING DIAGRAMS

PAINTING

CHASSIS DRAWINGS

CHASSIS FRAME DRAWINGS

MOUNTING OF CHASSIS EQUIPMENT

FUEL TANK

BATTERY

EXHAUST SYSTEM

NB: This manual pertains the body and chassis mounting of Hino 300 Series trucks. It does not include information regarding the engine and its accessories. For further details, please refer to the contents.
