JCB 2.5D 2.5G 3.0D 3.0G 3.5D 3.0D 4X4 3.5D 4X4 3.0D HIGH LIFT TELETRUK SERVICE MANUAL

JCB 2.5D 2.5G 3.0D 3.0G 3.5D 3.0D 4X4 3.5D 4X4 3.0D HIGH LIFT TELETRUK SERVICE MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 545
FILE SIZE: 38.9MB

MODEL COVERED:

TELETRUK TIER 2 MACHINES:

2.5 G, 3.0 G, FROM 1175813 TO 1176999

3.0D 4X4, FROM 1175813 TO 1176569

3.5D, FROM 1175813 TO 1176572

3.5D 4X4, FROM 1175813 TO 1176591

3.0 D HIGH LIFT, FROM 1175813 TO 1176593

TELETRUK TIER 3 MACHINES:-

TELETRUK 2.5D, 3.0D, FROM SN 1176570

TELETRUK 3.0D 4X4, FROM SN 1176573

TELETRUK 3.5D, FROM SN 1176592

TELETRUK 3.5D 4X4, FROM SN 1176586

TELETRUK 3.0 D HIGH LIFT, FROM SN 1176594

WHERE D INDICATES DIESEL AND G INDICATES LIQUID

PETROLEUM GAS (LPG)

PUB NO: 9803/9510-05


CONTENTS:

SECTION 1 - GENERAL INFORMATION

SECTION 2 - CARE AND SAFETY

SECTION 3 - MAINTENANCE

SECTION A - ATTACHMENTS

SECTION B - BODY AND FRAMEWORK

SECTION C - ELECTRICS

SECTION D - CONTROLS

SECTION E - HYDRAULICS

SECTION F - TRANSMISSION

SECTION G - BRAKES

SECTION H - STEERING

SECTION K - ENGINE
