JCB 2CX AND VARIANTS BACKHOE LOADER WORKSHOP SERVICE REPAIR, OPERATOR'S MANUAL

JCB 2CX AND VARIANTS BACKHOE LOADER WORKSHOP SERVICE REPAIR, OPERATOR'S MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 2,710
FILE SIZE: 105MB

MODEL COVERED:

2CX & VARIANTS,  From M/c No. 930000 ONWARD


ENGINE COVERED:

3.99L 4-CYLINDER, 67BHP, 1004-40AJ, NATURALLY ASPIRATED

4.23L 4-CYLINDER, 75BHP, 1004-42AR, NATURALLY ASPIRATED

4.00L 4-CYLINDER, 75BHP, 1000 SERIES, NATURALLY ASPIRATED


CONTENTS:

GENERAL INFORMATION

CARE & SAFETY

MAINTENANCE

BODY & FRAMEWORK

CAB-TANKS-BOOMS

AIR CONDITIONING

HYDRAULIC SYSTEM

SCHEMATIC CIRCUIT

FAULT FINDING

PUMP-VALVE-RAMS

ELECTRIC SYSTEM

BATTERY SYSTEM

ALTERNATOR SYSTEM

STARTER MOTOR

SAFE-LOAD INDICATOR

TRANSMISSION

FRONT & REAR AXLE

DRIVE HEAD SYSTEM

DRIVESHAFT & HUBS

DIFFERENTIAL & PROPSHAFT

BRAKE SYSTEM

PARKING BRAKE

STEERING SYSTEM

ENGINE SYSTEM

EXTRAS INCLUDED:

OPERATOR MANUAL

JCB MATERIAL SAFETY DATA SHEETS (MSDS)

TECHNICAL BULLETIN

PARTS LISTS
