JCB 412S 414S 416S WHEEL LOADER SHOVEL WORKSHOP SERVICE REPAIR MANUAL

JCB 412S 414S 416S WHEEL LOADER SHOVEL WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 1,103
FILE SIZE: 82.8MB

MODEL COVERED:

JCB 412S 414S 416S WHEEL LOADER SHOVEL

THIS MANUAL PROVIDES INFORMATION FOR THE FOLLOWING MODEL(S) IN THE JCB MACHINE RANGE:

– 412S FROM MACHINE SERIAL NUMBER 535000.

– 414S FROM MACHINE SERIAL NUMBER 537000.

– 416S FROM MACHINE SERIAL NUMBER 543000.

SMOOTHSHIFT TRANSMISSION IS INSTALLED FROM THE FOLLOWING MODELS:

– 412S FROM MACHINE SERIAL NUMBER 535500.

– 414S FROM MACHINE SERIAL NUMBER 537300.

– 416S FROM MACHINE SERIAL NUMBER 543100.

TIER 3 EN474 MACHINES FROM THE FOLLOWING MODELS

THE INFORMATION SUPPLIED IN THIS MANUAL FOR THE 414S

MACHINE ALSO APPLIES TO THE 416S MACHINE EXCEPT WHERE SPECIFIED.

– 412S FROM SN 1421800 TO 1421999

– 414S FROM SN 1242500 TO 1242999

– 416S FROM SN 1243500 TO 1243999.

ENGINE:

JCB 444 SERIES

PUB NO: 9803/4170-16


CONTENTS:

SECTION 1 - GENERAL INFORMATION

SECTION 2 - CARE AND SAFETY

SECTION 3 - ROUTINE MAINTENANCE

SECTION A - ATTACHMENTS

SECTION B - BODY AND FRAMEWORK

SECTION C - ELECTRICS

SECTION E - HYDRAULICS

SECTION F - TRANSMISSION

SECTION G - BRAKES

SECTION H - HYDRAULIC STEERING

SECTION K - ENGINE

NB: The bookmark or hyperlink provided in this manual is non-functional. You are required to either scroll through the manual or utilize the search feature to locate the relevant keywords.
