JCB 426 435 436 446 WHEEL LOADER SHOVEL WORKSHOP SERVICE REPAIR MANUAL

JCB 426 435 436 446 WHEEL LOADER SHOVEL WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 1,366
FILE SIZE: 187MB

MODEL COVERED:

JCB 426 435 436 446 WHEEL LOADER SHOVEL

– 426 WHEELED LOADING SHOVEL FROM MACHINE SERIAL NUMBER 531001

– 427 WHEELED LOADING SHOVEL FROM MACHINE SERIAL NUMBER 533001

– 435 WHEELED LOADING SHOVEL FROM MACHINE SERIAL NUMBER 533001

– 436 WHEELED LOADING SHOVEL FROM MACHINE SERIAL NUMBER 533001

– 437 WHEELED LOADING SHOVEL FROM MACHINE SERIAL NUMBER 533001

– 446 WHEELED LOADING SHOVEL FROM MACHINE SERIAL NUMBER 540000 TO 540011

ENGINE:

426 - PERKINS 1006-6T7

436 - PERKINS 1006-6T4

446 - 6CT 8.3 - 170

CUMMINS C SERIES, 6 CYLINDER TURBO CHARGED DIESEL, WATER COOLED

426B - 1006-6T

436B - 1006-TW

426 FROM 532500 - NEW BTAA 5.9 - C / SO 18487 TIER 2

436 FROM 534200 - NEW BTAA 5.9 - C / SO 18521 TIER 2

426E FROM 1295000 - QSB6.7/SO 75928 TIER 3

436E FROM 1410000 - QSB6.7/SO 75928 TIER 3

427 - QSB 6.7L TIER 4

437 - QSB 6.7L TIER 4

PUB NO: 9803-4160-17


CONTENTS:

SECTION 1 - GENERAL INFORMATION

SECTION 2 - CARE AND SAFETY

SECTION 3 - ROUTINE MAINTENANCE

SECTION A - ATTACHMENTS

SECTION B - BODY AND FRAMEWORK

SECTION C - ELECTRICS

SECTION E - HYDRAULICS

SECTION F - TRANSMISSION

SECTION G - BRAKES

SECTION H - HYDRAULIC STEERING

SECTION K - ENGINE

NB: The bookmark or hyperlink provided in this manual is non-functional. You are required to either scroll through the manual or utilize the search feature to locate the relevant keywords.
