JCB JS AUTO RANGE JCB ENGINE TRACKED EXCAVATOR WORKSHOP SERVICE REPAIR MANUAL

JCB JS AUTO RANGE JCB ENGINE TRACKED EXCAVATOR WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 959
FILE SIZE: 82.8MB

MODEL COVERED:

JS AUTO RANGE - TRACKED EXCAVATORS - JCB ENGINE

– JCB JS115 FROM SERIAL NO. 01786452 TO 01786462

– JCB JS130 FROM SERIAL NO. 01786463 TO 01786863

– JCB JS145 FROM SERIAL NO. 01786864 TO 01788884

– JCB JS160/JS180 FROM SERIAL NO. 01776500 TO 01777499

– JCB JS200/JS210/JS220 FROM SERIAL NO. 01782453 TO 01786451

– JCB JS200 (EXPORT) (CHINA) FROM SERIAL NO. 2281479 TO 2282479

– JCB JS220 (EXPORT) (CHINA) FROM SERIAL NO. 2282480 TO 2283480

– JCB JS210 (CHINA) FROM SERIAL NO. 2283481 TO 2285481

– JCB JS230 (CHINA) FROM SERIAL NO. 2285482 TO 2287482

ENGINE:

JS115/130/145 - TCAE-74:

JCB 444 DIESEL MAX IN-LINE 4

CYLINDER, TURBO CHARGED -CHARGE COOLED

JS160/JS180 - TCAE-97:

JCB 444 DIESEL MAX IN-LINE 4

CYLINDER, TURBO CHARGED -CHARGE COOLED

JS200/210/220/230 - TCAE-129:

JCB 448 DIESEL MAX IN-LINE 4

CYLINDER, TURBO CHARGED -CHARGE COOLED

PUB: 9813/1000-4


CONTENTS:

SECTION 1 - GENERAL INFORMATION

SECTION 2 - CARE AND SAFETY

SECTION 3 - ROUTINE MAINTENANCE

SECTION B - BODY & FRAMEWORK

SECTION C - ELECTRICS

SECTION E - HYDRAULICS

SECTION F - TRANSMISSION

SECTION J - TRACK & RUNNING GEAR

SECTION K - ENGINE

NB: The bookmark or hyperlink provided in this manual is non-functional. You are required to either scroll through the manual or utilize the search feature to locate the relevant keywords.
