JCB JS240 JS260 JS330 JS360 TIER 4 TRACKED EXCAVATOR

JCB JS240 JS260 JS330 JS360 TIER 4 TRACKED EXCAVATOR SERVICE REPAIR MANUAL

Regular price $27.90
Sale price $27.90 Regular price
Unit price
Product description

JCB JS240 JS260 JS330 JS360 TIER 4 TRACKED EXCAVATOR SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 978
FILE SIZE: 223MB


MODEL COVERED:

JCB JS240 JS260 JS330 JS360 TIER 4

JCB JS240, 260 TIER 4 FROM SERIAL NUMBER 2050000 TO 2050249.

JS330 TIER 4 FROM SERIAL NUMBER 2050500 TO 2050749.

JS360 TIER 4 FROM SERIAL NUMBER 2050750 TO 2050999.

ENGINE:

4HK1X-S TIER 4

ISUZU 4HK1 4-CYCLE/WATER COOLED TYPE, INLINE 4 CYLINDER OHC

PUB: 9813/1250-1


CONTENTS:

SECTION 1 - GENERAL INFORMATION

SECTION 2 - CARE AND SAFETY

SECTION 3 - MAINTENANCE

SECTION B - BODY & FRAMEWORK

SECTION C - ELECTRICS

SECTION E - HYDRAULICS

SECTION F - TRANSMISSION

SECTION J - TRACK AND RUNNING GEAR

SECTION K - ENGINE


NB: The bookmark or hyperlink provided in this manual is non-functional. You are required to either scroll through the manual or utilize the search feature to locate the relevant keywords.
