JCB JZ235 JZ255 TIER III AUTO TRACKED EXCAVATOR SERVICE REPAIR MANUAL

JCB JZ235 JZ255 TIER III AUTO TRACKED EXCAVATOR SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 830
FILE SIZE: 70.3MB

MODEL COVERED:

JCB JZ235 JZ255 TIER III AUTO TRACKED EXCAVATOR

JCB JZ235/255 FROM SERIAL NUMBER 1234500 TO 1235499

ENGINE:

4HK1X-TIER III

ISUZU 4HK1 4-CYCLE/WATER COOLED TYPE, INLINE 4 CYLINDER OHC

PUB: 9803/6560-5


CONTENTS:

SECTION 1 - GENERAL INFORMATION

SECTION 2 - CARE AND SAFETY

SECTION 3 - ROUTINE MAINTENANCE

SECTION B - BODY & FRAMEWORK

SECTION C - ELECTRICS

SECTION E - HYDRAULICS

SECTION F - TRANSMISSION

SECTION J - TRACK AND RUNNING GEAR

SECTION K - ENGINE

NB: The bookmark or hyperlink provided in this manual is non-functional. You are required to either scroll through the manual or utilize the search feature to locate the relevant keywords.
