KAWASAKI ER-6F NINJA 650R ABS EX650A 2005-2010 BIKE SERVICE REPAIR, PARTS MANUAL

KAWASAKI ER-6F NINJA 650R ABS EX650A 2005-2010 BIKE SERVICE REPAIR, PARTS MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 1,463
FILE SIZE: 35.8MB

ENGINE SPECIFICATION:

ENGINE TYPE...4-STROKE, DOHC, 2-CYLINDER

COOLING SYSTEM...LIQUID-COOLED

BORE AND STROKE...83 × 60 MM (3.3 × 2.4 IN.)

DISPLACEMENT...649 CM³ (39.60 CU IN.)

COMPRESSION RATIO 11.3 : 1

CARBURETION SYSTEM...FI (FUEL INJECTION) KEIHIN TTK38 × 2

STARTING SYSTEM...ELECTRIC STARTER

IGNITION SYSTEM...BATTERY AND COIL (TRANSISTORIZED)

TIMING ADVANCE...ELECTRONICALLY ADVANCED (DIGITAL IGNITER)


CONTENTS:

GENERAL INFORMATION

MAINTENANCE

FUEL SYSTEM

COOLING SYSTEM

ENGINE TOP END

CLUTCH

LUBRICATION SYSTEM

ENGINE REMOVAL/INSTALLATION

CRANKSHAFT/TRANSMISSION

WHEELS/TIRES

FINAL DRIVE

BRAKES

SUSPENSION

STEERING

FRAME

ELECTRICAL SYSTEM

PARTS DIAGRAM
