KOBELCO F4D F4H NEF TIER 4A DIESEL ENGINE SERVICE REPAIR MANUAL

KOBELCO F4D F4H NEF TIER 4A DIESEL ENGINE SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 330
FILE SIZE: 25MB

ENGINES COVERED:

F4DFE613A*A, F4DFE613B*A, F4DFE613C*A, F4DFE613D*A, F4DFE613G*A,

F4DFE613H*A, F4DFE613J*A, F4DFE613K*A, F4DFE613L*A, F4HFE413H*A,

F4HFE6131*A, F4HFE613G*A, F4HFE613H*A, F4HFE613J*A, F4HFE613K*A,

F4HFE613P*A, F4HFE613R*A, F4HFE613X*A, F4HFE613Y*A

4-STROKE DIESEL ENGINE

TURBOCHARGED WITH INTERCOOLER

4 & 6 CYLINDERS, 4 VALVES PER CYLINDER

PART NO:

84586860

ISSUED:

JANUARY, 2012


CONTENTS:

INTRODUCTION

HYDRAULIC, PNEUMATIC, ELECTRICAL, ELECTRONIC SYSTEMS A

ELECTRICAL POWER SYSTEM

ENGINE AND PTO IN

ENGINE

FUEL AND INJECTION SYSTEM

AIR INTAKE SYSTEM

EXHAUST SYSTEM

ENGINE COOLANT SYSTEM

EXHAUST SYSTEM EMISSIONS CONTROL

LUBRICATION SYSTEM

STARTING SYSTEM

The Kobelco F4D/F4H NEF Tier 4A Engine Service and Repair Manual is a comprehensive, factory-authorized guide. Spanning hundreds of pages, it equips technicians with specifications, diagnostics, and step-by-step procedures for complete mechanical and electronic overhauls, including common rail fuel systems.
