MERCURY MARINE 40 50 60 HP EFI 4-STROKE OUTBOARD 2002-2007 SERVICE REPAIR MANUAL

MERCURY MARINE 40 50 60 HP EFI 4-STROKE OUTBOARD 2002-2007 SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 590
FILE SIZE: 17.5MB

MODEL COVERED:

S/N 0T409000 and up, 2002 TO 2007

40/50/60 ELPT

40/50/60 ELPT BIGFOOT


CONTENTS:

SECTION 1 – IMPORTANT INFORMATION

A – SPECIFICATIONS

B – MAINTENANCE

C – GENERAL INFORMATION

D – OUTBOARD MOTOR INSTALLATION

SECTION 2 – ELECTRICAL

A – IGNITION

B – CHARGING & STARTING SYSTEM

C – TIMING, SYNCHRONIZING & ADJUSTING

SECTION 3 – ELECTRONIC FUEL INJECTION

A – THEORY OF OPERATION

B – DIAGNOSTICS AND TROUBLESHOOTING

C – SERVICE PROCEDURES

D – EMISSIONS

SECTION 4 – POWERHEAD

A – CYLINDER HEAD

B – CYLINDER BLOCK/CRANKCASE

C – LUBRICATION

SECTION 5 – MID-SECTION

A – CLAMP/SWIVEL BRACKETS & DRIVE SHAFT HOUSING

B – POWER TRIM

C – MANUAL TILT ASSIST

SECTION 6 – LOWER UNIT

A – NON-BIGFOOT GEAR HOUSING

B – BIGFOOT GEAR HOUSING

SECTION 7 – ATTACHMENTS/CONTROL LINKAGE

A – THROTTLE/SHIFT LINKAGE

B – TILLER HANDLE

SECTION 8 – COLOR WIRING DIAGRAMS
