MERCURY MERCRUISER STERNDRIVE R MR ALPHA 1 ALPHA 1 SS # 6 SERVICE REPAIR MANUAL

MERCURY MERCRUISER STERNDRIVE R MR ALPHA 1 ALPHA 1 SS # 6 SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 566
FILE SIZE: 17.6MB

                                  MODEL COVERED:

Transom Assemblies

Model-----------------------------------------------------------------------Serial Number

MC 120R/140B/185R/488R/898R/228R/260R .............................6216687 – 6849289

MC 120MR/140MR/170MR/185MR/190MR/200MR/

230MR/260MR/300 Tempest MR..................................................6849290 – 0A471374

MC Alpha One/Alpha One SS ......................................................0A471375 and Above

Sterndrive Units

                                           MC 120R-260R

Original Ratio-------Ratio If Serviced With 13:21 Gears------------Serial Number

1.98:1 ..................................1.94:1 .....................................................6237861-6854392

1.84:1................................. 1.81:1 ....................................................6225577-6862701

1.65:1 .................................1.62:1 .....................................................6268065-6810537

1.50:1 ..................................1.47:1 ......................................................6229158-6847029

1.32:1 ...................................1.29:1 ....................................................6231571-6663947

                                    MC 120 MR - 300 TEMPEST MR

Original Ratio------Ratio If Serviced With 13:28 Gears--------- Serial Number

1.98:1 ...............................1.94:1 ....................................................6854393-0A476746

1.84:1 ..............................1.81:1.................................................... 6862702-0A470164

1.65:1 ..............................1.62:1.................................................... 6810538-0A475786

1.50:1 .............................1.47:1...................................................... 6847030-0A479506

                               MC ALPHA ONE / ALPHA ONE SS

Original ------Ratio If Serviced --- R.H. Serial Number---L.H. Serial Number

  Ratio           With 13:28 Gears

1.98:1............1.98:1...................0A476747 and Above................0C881740 and Above

1.84:1 ...........1.84:1 ...................0A470165 and Above ..............0C884040 and Above

1.65:1 ...........1.65:1 ...................0A475787 and Above.............. 0C881790 and Above

1.50:1 ...........1.50:1 ..................0A479507 and Above ..............0C852908 and Above

1.32:1 ...........1.32:1 ...................0A613927 and Above

Alpha One SS

1.50:1/1.32:1....1.50/1.32:1 .......0A545004 and Above

Sea Ray Sterndrive Units and Transom Assembly (Oyster White)

Original Ratio--------Ratio If Serviced With---------- Serial Number

                                            13:21 Gears

1.98:1..................................................................... 0B803866-0C348031

1.84:1 .....................................................................0B800854-0C343526

1.50:1 ......................................................................0B796473-0C340666

1.32:1 ......................................................................0B804807-0C340030

Transom Assembly................................................ 0B815811-0C340333

CONTENTS:

GENERAL INFORMATION

MAINTENANCE

TROUBLESHOOTING

REMOVAL & INSTALLATION

ADJUSTMENTS

DRIVESHAFT HOUSING

GEAR HOUSING

TRANSOM ASSEMBLY

TRANSOM DISASSEMBLY

POWER TRIM

TRIM CYLINDERS

DUAL POWER TRIM CONTROL

AUTO TRIM II

POWER STEERING

MANUAL STEERING

CORROSION PROTECTION
