NEW HOLLAND 480FI 480 FI ROTARY HARVESTING HEADER SERVICE REPAIR MANUAL

NEW HOLLAND 480FI 480 FI ROTARY HARVESTING HEADER SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 232
FILE SIZE: 8.76MB

MODEL COVERED:

480FI ROTARY HARVESTING HEADER

ISSUED:

84539587A 01 AUGUST 2011


CONTENTS:

SECTION 05-SAFETY

GROUP 05-SAFETY MEASURES

SECTION 10-GENERAL LNFORMATION

GROUP 00-LDENTIFICATION VIEW AND DESCRIPTION

GROUP 05-LUBRICANTS, GEAR OIL AND COOLANT

GROUP 10-TORQUES

GROUP 15-CAPACITIES

GROUP  20-SPECIFICATIONS

SECTION 40-ELECTRICAL SYSTEM

GROUP 05-GENERAL

SECTION 50-POWER TRAIN

GROUP 05-GEAR BOX

GROUP 10-FRICTION CLUTCHES

GROUP 15-TRANSMISSION - FEED DRUMS

GROUP 20-TRANSMISSION - LNNER GATHERING DRUMS

GROUP 25-TRANSMISSION - OUTER GATHERING DRUMS

GROUP 30-U-JOINTED SHAFT

SECTION 70-HYDRAULIC SYSTEM

GROUP 05-HYDRAULIC SYSTEM

SECTION 80-MISCELLANEOUS

GROUP 05-OUTER FOLDING SECTIONS

SECTION 100-FEED SYSTEM

GROUP 05-LNNER GATHERING DRUMS

GROUP 10-OUTER GATHERING DRUMS

GROUP 15-ROTORS

GROUP 20-FEED DRUMS

SECTION 212-DIAGNOSING MALFUNCTIONS

GROUP  05-TROUBLESHOOTING

SECTION 99-SPECIAL TOOLS

GROUP 05-SPECIAL TOOLS (DEALER-FABRICATED)

GROUP 10-SPECIAL TOOLS (AVAILABLE AS SPARE PARTS)
