NEW HOLLAND L465 LX465 LX485 SKID STEER LOADER FACTORY SERVICE REPAIR MANUAL

NEW HOLLAND L465 LX465 LX485 SKID STEER LOADER FACTORY SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 808
FILE SIZE: 138MB

MODEL COVERED:

NEW HOLLAND L465 LX465 LX485

MODEL SERIAL NUMBER RANGE

L465 - 848451 TO 999999 AND 0001 TO 3087

LX465 - 851851 TO 999999 AND 0001 TO 9259

LX485 - 871001 TO 999999 AND 0001 TO 20384

LATER MODELS - WITH ACCESSORY RELAY AND

SECOND FUSE BLOCK INSTALLED FROM FACTORY

MODEL SERIAL NUMBER RANGE

L465 - 3088 TO 848450

LX465 - 9260 TO 851850

LX485 - 20385 TO 871000

ENGINE MODEL

L465, LX465 - N843

LX485 - N843H

ISSUED:

VOL.1

86587274

86587275 4/99


CONTENTS:

SECTION 1 - GENERAL INFORMATION

SECTION 2 - ENGINE

SECTION 3 - ELECTRICAL SYSTEM

SECTION 4 - FINAL DRIVE, AXLES, BRAKES

SECTION 5 - HYDROSTATIC SYSTEM AND STEERING SYSTEM

SECTION 6 - HYDRAULIC SYSTEM

SECTION 7 - SEAT, CAB, ROPS, BOOM LOCK, BOOM,

ATTACHMENT MOUNTING PLATE

SECTION 8 - OPTIONAL EQUIPMENT
