NEW HOLLAND VL 5090 6040 6050 6060 6070 6080 6090, VM3090 VM4090 VN2090 GRAPE HARVESTER SERVICE MANUAL

NEW HOLLAND VL 5090 6040 6050 6060 6070 6080 6090, VM3090 VM4090 VN2090 GRAPE HARVESTER SERVICE MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 634
FILE SIZE: 39.3MB

MODEL COVERED:

VL5090

VL6040

VL6050

VL6060

VL6070

VL6080

VL6090

VM3090

VM4090

VN2090

87613083B

07-2008

PREVIOUS NAME                NEW NAME

VL660 UP TO SERIES 024 VL6090 STARTING FROM SERIES 025

VL640 UP TO SERIES 022 VL6080 STARTING FROM SERIES 023

VL630 UP TO SERIES 022 VL6070 STARTING FROM SERIES 023

VL620 UP TO SERIES 021 VL6060 STARTING FROM SERIES 022

VL610 UP TO SERIES 021 VL6050 STARTING FROM SERIES 022

VL600 UP TO SERIES 004 VL6040 STARTING FROM SERIES 005

VL570 UP TO SERIES 008 VL5090 STARTING FROM SERIES 009

VM460 UP TO SERIES 008 VL4090 STARTING FROM SERIES 009

VM370 UP TO SERIES 008 VL3090 STARTING FROM SERIES 009

VN300 UP TO SERIES 003 VL2090 STARTING FROM SERIES 004


CONTENTS:

MAINTENANCE

MACHINE ARRANGEMENT

ENGINE

HYDROSTATIC TRANSMISSION

BRAKES

HYDRAULIC SYSTEM

FRAME

STEERING

WHEELS

CAB

ELECTRICAL SYSTEM

HARVESTING EQUIPMENT

PRODUCT FEEDING

CLEANING

HOPPERS

ACCESSORIES
