SAME EXPLORER 2 3 75 85 95 100 T, TB AND SPECIAL TRACTOR SERVICE REPAIR MANUAL

SAME EXPLORER 2 3 75 85 95 100 T, TB AND SPECIAL TRACTOR SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 2,572
FILE SIZE: 117MB

MODEL COVERED:

EXPLORER 3 85

EXPLORER 3 100

EXPLORER 75

EXPLORER 85

EXPLORER 95

EXPLORER 75 T-TB

EXPLORER 85 T-TB

EXPLORER 95 T-TB

EXPLORER II SPECIAL

70 - 75 HP

80 - 85 - 90 - 95 HP


CONTENTS:

SECTION 00 CONTAINS THE GENERAL SAFETY RULES, INFORMATION ON HOW TO USE AND UPDATE

THE MANUAL, THE SYMBOLS USED, THE PRODUCTS REQUIRED, THE STANDARD TIGHTENING

TORQUES AND A CONVERSION TABLE FOR UNITS OF MEASUREMENT.

SECTION 10 CONTAINS TECHNICAL DESCRIPTIONS AND INFORMATION REGARDING THE MECHANICAL

AND HYDRAULIC OPERATION OF MACHINE COMPONENTS, THE DESIGNATIONS OF

THE VARIOUS COMPONENTS, HYDRAULIC DIAGRAMS AND GENERAL TECHNICAL DATA.

SECTION 20 CONTAINS INFORMATION ON THE TRACTOR'S ELECTRICAL AND ELECTRONIC SYSTEMS,

THE PROCEDURES FOR PUTTING INTO SERVICE, THE LIST OF ALARMS AND A GUIDE TO THE

USE OF THE SOFTWARE REQUIRED FOR TRACTOR AND ENGINE CONFIGURATION AND ACCESS

TO DIAGNOSTIC CODES.

SECTION 30 CONTAINS THE METHODS, CHECKS AND ADJUSTMENTS REGARDING THE EXTERNAL

COMPONENTS; THE OPERATIONS DEALT WITH IN THIS SECTION DO NOT REQUIRE REMOVAL

OF THE VARIOUS ASSEMBLIES THAT FORM THE TRACTOR FRAME AND CAB.

SECTION 40 CONTAINS INFORMATION AND DIAGRAMS REGARDING THE MACHINE'S ELECTRICAL

AND ELECTRONIC SYSTEMS
