SAME IRON 100 110 120 HILINE HI-LINE TRACTOR WORKSHOP REPAIR SERVICE MANUAL

SAME IRON 100 110 120 HILINE HI-LINE TRACTOR WORKSHOP REPAIR SERVICE MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 777
FILE SIZE: 17.7MB

MODEL COVERED:

IRON 100 HI-LINE

IRON 110 HI-LINE

IRON 120 HI-LINE

ISSUED:

JULY, 2006


CONTENTS:

SECTION 00 CONTAINS THE GENERAL SAFETY RULES, INFORMATION ON HOW TO USE AND UPDATE

THE MANUAL, THE SYMBOLS USED, THE PRODUCTS REQUIRED, THE STANDARD

TIGHTENING TORQUES AND A CONVERSION TABLE FOR UNITS OF MEASUREMENT.

SECTION 10 CONTAINS TECHNICAL DESCRIPTIONS AND INFORMATION REGARDING THE

MECHANICAL AND HYDRAULIC OPERATION OF MACHINE COMPONENTS, THE

DESIGNATIONS OF THE VARIOUS COMPONENTS, HYDRAULIC DIAGRAMS AND GENERAL

TECHNICAL DATA.

SECTION 20 CONTAINS THE USER GUIDES FOR THE SOFTWARE NEEDED TO CONFIGURE THE

MACHINE AND THE ENGINE AND TO READ ANY FAULT DIAGNOSIS.

SECTION 30 CONTAINS THE METHODS, CHECKS AND ADJUSTMENTS REGARDING THE EXTERNAL

COMPONENTS; THE OPERATIONS DEALT WITH IN THIS SECTION DO NOT REQUIRE

REMOVAL OF THE VARIOUS ASSEMBLIES THAT FORM THE TRACTOR FRAME AND CAB.

SECTION 40 CONTAINS INFORMATION AND DIAGRAMS REGARDING THE MACHINE'S ELECTRICAL

AND ELECTRONIC SYSTEMS
