TAKEUCHI TB153FR COMPACT EXCAVATOR WORKSHOP SERVICE, PARTS, OPERATOR'S MANUAL

TAKEUCHI TB153FR COMPACT EXCAVATOR WORKSHOP SERVICE, PARTS, OPERATOR'S MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 1,330
FILE SIZE: 66.1MB

MODEL COVERED:

TAKEUCHI TB153FR COMPACT EXCAVATOR

SERIAL NO:

158200004 & UP

BOOK NO:

CJ2E000

ENGINE:

YANMAR 4TNV88-PTBZ1


CONTENTS:

I . GENERAL

II . SPECIFICATIONS

III. MACHINE CONFIGURATION

IV. HYDRAULIC UNITS

V . TROUBLESHOOTING

VI. ENGINE

EXTRAS INCLUDED:

OPERATOR'S MANUAL

PARTS CATALOG MANUAL

This manual is intended for persons who engage in maintenance operations, and explains procedures for
disassembly and reassembly of the machine, check and maintenance procedures, maintenance reference values,
troubleshooting and outline specifications, etc. Please use this manual as a reference in service activities to improve
maintenance techniques.
Further, please be advised that items contained in this manual are subject to change without notice due to design
modifications, etc.
MACHINE FRONT AND REAR, LEFT AND RIGHT
The end where the dozer blade is mounted is the front and the end with the travel motors is the rear. Also the right
and left sides of the operator when he is seated in the driver’s seat are the right and left sides of the machine.
MACHINE SERIAL NUMBER
The machine serial number is stamped on the identification plate. When sending reports and inquiries, and when
ordering parts, etc., be sure to include this number.
MANUAL CONTROL
Information on those to whom this manual is distributed is recorded in the ledger in the section in charge at this
company, so please decide on a person to be in charge of it and control it. When there are updates or additions, etc.,
we will notify the person in charge.
