TAKEUCHI TB68 COMPACT EXCAVATOR WORKSHOP SERVICE REPAIR, PARTS MANUAL

TAKEUCHI TB68 COMPACT EXCAVATOR WORKSHOP SERVICE REPAIR, PARTS MANUAL
LANGUAGE: ENGLISH, JAPANESE
FORMAT: PDF
PAGES: 442
FILE SIZE: 49.4MB

MODEL COVERED:

TAKEUCHI TB68 COMPACT EXCAVATOR

PUB. 1


CONTENTS:

GENERAL

SPECIFICATIONS

MACHINE CONFIGURATION

HYDRAULIC UNITS

TROUBLESHOOTING

EXTRAS INCLUDED:

PARTS MANUAL

This manual is intended for persons who engage in maintenance operations,
and explains procedures for disassembly and reassembly procedures for the
machine, check and maintenance procedures, maintenance reference values,
troubleshooting and outline specifications, etc. Please use this manual as a
reference in service activities to improve maintenance techniques.
Further, please be advised that items contained in this manual are subject to
change without notice due to design modifications, etc.
MACHINE FRONT AND REAR, LEFT AND RIGHT
The end where the dozer blade is mounted is the front and the end with
the track gearboxes is the rear. Also the right and left sides of the operator
when he is seated in the driver's seat are the right and left sides of the
machine.
MACHINE SERIAL NUMBER
The machine serial number is stamped on the identification plate on the side
of the frame opposite the driver's seat. When sending reports and inquiries,
and when ordering parts, etc., be sure to include this number.
MANUAL CONTROL
Information on those to whom this manual is distributed is recorded in the
lodger in the section in charge at this company, so please decide on a person
to be in charge of it and control it. When there are updates or additions,
etc., we will notify the person in charge.
