TOYOTA 7M-GE 7M-GTE ENGINE WORKSHOP SERVICE REPAIR MANUAL

TOYOTA 7M-GE 7M-GTE ENGINE WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF (SCANNED PDF)
PAGES: 677
FILE SIZE: 50MB

7M-GE ENGINE:

The Toyota 7M-GE introduced in the early months of 1986 is a 3.0 litre (2954 cc) 24-valve (4 valves per cylinder) DOHC/fuel injected engine. The valves are spaced at a performance-oriented 50° angle. Cylinder bore is 83 mm (3.27 in) and stroke is 91 mm (3.58 in). The 7M-GE was produced from 1986 through 1992. Output was 190-204 hp (142-152 kW) at 6000 rpm and 185-196 ft·lbf (250-265 Nm) at 4800 rpm.


APPLICABLE MODEL:

1986–1992 Toyota Supra MkIII (MA70)

1989–1992 Toyota Cressida Mark II (MX83)

Toyota Chaser

Toyota Crown


7M-GTE ENGINE:

The turbocharged 7M-GTE was produced from 1986 to 1992. Output was 232 hp (173 kW) at 5600 rpm and 240 ft·lb (325 N·m) at 4000 rpm for most 5 psi (0.34 bar) versions.


APPLICABLE MODEL:

986–1992 Toyota Supra MkIII (MA70)

1986–1991 Toyota Soarer (MZ20/MZ21)


CONTENTS:

INTRODUCTION

SERVICE SPECIFICATION

ENGINE MECHANICAL

COOLING SYSTEM

LUBRICATION SYSTEM

STARTING SYSTEM

CHARGING SYSTEM

IGNITION SYSTEM

EFI SYSTEM

TURBOCHARGER SYSTEM
