YAMAHA YZF-R1 2009-2010 BIKE WORKSHOP SERVICE REPAIR MANUAL

YAMAHA YZF-R1 2009-2010 BIKE WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 526
FILE SIZE: 24.9MB

ENGINE SPECIFICATION:

Engine type.......................Liquid cooled 4-stroke, DOHC

Displacement......................998.0 cm³

Cylinder arrangement..............Forward-inclined parallel 4-cylinder

Bore × stroke.....................78.0 × 52.2 mm (3.07 × 2.06 in)

Compression ratio.................12.70 : 1

Standard compression

pressure (at sea level)...........1480 kPa/350 r/min (14.8 kgf/cm²/350 r/min,

210.5 psi/350 r/min)

Minimum–Maximum...................1290–1660 kPa/350 r/min (12.9–16.6 kgf/cm²/

350 r/min, 183.5–236.1 psi/350 r/min)

Starting system...................Electric starter

CONTENTS:

GENERAL INFORMATION

SERVICE SPECIFICATION

PERIODIC CHECKS AND ADJUSTMENTS

TROUBLESHOOTING

ENGINE

CAMSHAFT

CYLINDER HEAD

CLUTCH

CRANKCASE

CRANKSHAFT

TRANSMISSION

COOLING SYSTEM

FUEL SYSTEM

BRAKE

SWINGRAM

CHAINDRIVE

CHASSIS

ELECTRICAL SYSTEM
