YAMAHA YZF-R6 SERIES 2003-2005 BIKE WORKSHOP SERVICE REPAIR MANUAL

YAMAHA YZF-R6 SERIES 2003-2005 BIKE WORKSHOP SERVICE REPAIR MANUAL
LANGUAGE: ENGLISH
FORMAT: PDF
PAGES: 434
FILE SIZE: 20.1MB

MODEL COVERED:

YZF-R6R

YZF-R6SR

YZF-R6RC

YZF-R6SRC

ENGINE SPECIFICATIONS:

Engine type...............................................Liquid-cooled, 4-stroke, DOHC

Displacement............................................600 cm3 (36.61 cu.in)

Cylinder arrangement...............................Forward-inclined parallel 4-cylinder

Bore X stroke…………………………………………..65.5 44.5 mm (2.58 1.75 in)

Compression ratio…………………………………..12.4 : 1

Engine idling speed………………………………...1,250 1,350 r/min

Vacuum pressure at engine idling

speed.........................................................24 kPa (180 mmHg, 7.0872inHg)

Standard compression pressure

(at sea level)…………………………………………...1,550 kPa (15.50 kg/cm2,15.50 bar, 220.46 psi) at 400 r/min

CONTENTS:

GENERAL INFORMATION

SERVICE SPECIFICATION

PERIODIC CHECKS AND ADJUSTMENT

CHASSIS

ELECTRICAL SYSTEM

WHEEL AND BRAKE DISCS

STEERING

SWINGRAM

DRIVECHAIN

ENGINE

CAMSHAFT

CYLINDER HEAD

CRANKSHAFT

CLUTCH

STARTER

CRANKCASE

CRANKSHAFT

COOLING SYSTEM

FUEL INJECTION SYSTEM

IGNITION SYSTEM

TROUBLESHOOTING

WIRING DIAGRAM
